SPECIFICATIONS:
1.MATERIALS AND FINISH
HOUSING:GLASS FILED POLYESTER UL94V-0 PANTONE BLACK CONTACT:PHOSPHOR BRONZE T=0.35MM FLAT PIN PLATING:6u”GOLD PLATING OVER NICKEL
SHIELD: 0.20MM THICKNESS COPPER ALLOY WITH NICKEL PLATED SIGNAL PINS & LED PINS: TIN(SN)/NICKEL PLATING
2.MECHANICAL CHARACTERISTICS
DURABILITY: 750(MODULAR JACK) INSERTION/PLUG DIMENSION CYCLES
3.ELECTRICAL
INSULATION RESISTANCE: 500 MEGOHMS MIN. DIELECTRIC STRENGTH: 2250VDC.
4.ENVIRONMENTAL
OPERATING TEMPERATURE: 0℃~+70℃; STORAGE TEMPERATURE:-40℃~+85℃
