1.MATERIALS AND FlNISH
HOUSING :NYLON46( GLASS FILED POLYESTER UL94V-0)
CONTACT : PHOSPHOR BRONZE T =0.35MM FLAT PIN
PLATING : FU ” GOLD PLATING OVER NICKEL
SHIELD :0.2MM THICKNESS COPPER ALLOY WITH NICKEL PLATED
PCB RETENTION FRE – SOLDER :1LB MIN .
РСВ RETENTION POST – SOLDER :10 LBS MIN .
SIGNAL PINS :80U”~200U” TIN ( SN ) PLATING FINISH MIN .
OVER 30U”~100U” NICKEL
2.MECHANICALCHARACTERISTICS
DURABILITY :750(М ODULAR JACK ) INSERTION / PLUG DIMENSION CYCLES
3.ENVIRONMENTAL
OPERATING TEMPERATURE : O ℃~+70℃
STORAGE TEMPERATURE :-40℃~+85℃
