SFP Plus 2X1 Cage and Connector S2N3A23004BA4(Cross out ALL BEST R-DP-008040-7-F-N-62)

The S2N3A23004BA4 is an integrated SFP+ (Small Form-factor Pluggable Plus) 2X1 cage and connector assembly. It is designed to provide a high-performance, dual-stacked interface for high-speed data transmission modules, ensuring a reliable “vital connection” for networking hardware.

S2N3A23004BA4

Product Overview

This product features a stacked 2×1 configuration, allowing two SFP+ modules to be inserted into a single mechanical footprint on a PCB. It integrates both the metal EMI shielding cage and the electrical connector into one unit to simplify assembly and optimize port density.

Product Specifications

Interface Type: СФП+
Port Configuration: 2X1 (Stacked)
Measurement Unit: Millimeters (mm)
General Tolerances:
- Linear: .X±0.20, .XX±0.15, .XXX±0.10
- Angular: .X±1°, .XX±5°
Revision: A

Product Features

Integrated Design: Combines the cage and connector for streamlined board layout.
High Precision: Manufactured with tight tolerances (up to ±0.10mm) to ensure perfect alignment with SFP+ modules.
Standardized Footprint: Follows the SFP+ industry standard for compatibility with various transceivers.
Robust Construction: Developed by Vitalconn for high-reliability communication environments.

Applications

While the sources do not explicitly list applications, this type of SFP+ 2X1 stacked connector is typically used in:

Networking switches and routers.
Enterprise servers and storage systems.
Telecommunications infrastructure.
Data center high-speed I/O interfaces.

Packing Details

The product is packaged using blister trays. According to the technical drawing notes, adjacent blister trays are oriented at a specific degree relative to each other in the horizontal direction during placement to ensure stability and protection during transport.

FAQ

Q1. What is the port density of the S2N3A23004BA4?

A1: This model features a 2X1 stacked configuration, meaning it supports two SFP+ ports in a vertically stacked arrangement to save horizontal space on the PCB.

Q2. Who is the manufacturer of this connector?

A2: The product is manufactured by Vitalconn (http://www.vitalconn.com), as indicated on the technical drawing.

Q3. What are the precision standards for this part?

A3: The part is held to high manufacturing standards, with the most precise linear tolerance reaching ±0.10mm and angular tolerance reaching ±1°.
