180 Degree Vertical SMT 6P6C Tab Up RJ11 Connector JV110503U9A0(Cross out ADAM TECH MTJ-66KX1J-T1471)

Product Overview

The JV110503U9A0 is a Tab-Up SMT connector specifically engineered for “Vital Connections” in vertical PCB layouts. It provides a secure mechanical interface with a retention strength of 7.7 kgf between the jack and plug. Built for durability, it is rated for a minimum of 750 mating cycles and can operate in extreme temperature environments ranging from -40°C to +85°C.

Product Specifications

• Electrical:
  • Current Rating: 1.5 AMP.
  • Voltage Rating: 125 Volts AC.
  • Dielectric Strength: 1000 VAC RMS (50Hz or 60Hz) for 1 minute.
  • Insulation Resistance: 500 Mega Ohms minimum after 500V DC for 1 minute.
  • Contact Resistance: 30 Milliohms max (initial); 50 Milliohms max (after durability test).
• Mechanical:
  • Insertion Force: 2.2 kgf maximum.
  • Retention Strength: 7.7 kgf between jack and plug.
  • Durability: 750 cycles minimum at a speed of 12.5mm/minute.
• Material:
  • Housing: PA9T, UL94V-0, Black.
  • Terminal: Phosphor Bronze (T=0.30mm).
  • Plating: 6u” Gold plating on contact area.

Product Features

• Vertical 180-degree entry orientation for specialized PCB designs.
• Surface Mount Technology (SMT) design for automated assembly efficiency.
• High-temperature PA9T material, making it suitable for modern reflow soldering processes.
• 6u” Gold Plating provides enhanced protection against corrosion and signal loss.
• Tab-Up design to accommodate specific mechanical latching requirements.

Applications The sources do not explicitly list specific applications; however, based on the 6P6C configuration and vertical SMT design, this product is typically used in:

• Telecommunications equipment (Landline phones, modems).
• Networking hardware and routers.
• Industrial control systems.
• Security and monitoring devices. (Please note: These applications are based on general industry standards and are not directly stated in the sources.)

Packing Details The sources indicate the use of Mylar on the top surface, which is standard for providing a suction surface for automated Pick-and-Place vacuum nozzles during SMT assembly. While specific carton quantities are not listed, this design is consistent with Tape and Reel or specialized tray packaging used for surface mount components.

FAQ (Frequently Asked Questions)

What is the operating temperature range for this connector?

The connector is designed to function reliably in temperatures ranging from -40°C to +85°C, making it suitable for both standard and industrial environments.

How many times can this connector be plugged and unplugged?

It has a mechanical durability rating of at least 750 cycles when tested at a speed of 12.5mm per minute.

What are the key electrical safety ratings for the JV110503U9A0?

It supports a current rating of 1.5AMP and a voltage of 125V AC, with a dielectric strength capable of withstanding 1000 VAC RMS for one minute.
