USB Type-C 6-Pin SMT Connector UC31-1E1H1A103-0HR-30

Product Overview

The UC31-1E1H1A103-0HR-30 USB Type-C 6-pin SMT connector from VITALCONN provides a cost-effective, compact solution for devices requiring USB Type-C form factor without full 24-pin complexity. This USB Type-C 6-pin SMT connector features a low 6.5mm profile height and essential pin assignments for GND, VBUS, CC1, and CC2, enabling USB 2.0 data transfer and basic Power Delivery applications. The SMT mounting type ensures efficient automated assembly, while the compact form factor of this USB Type-C 6-pin SMT connector makes it perfect for space-constrained consumer electronics, IoT devices, and embedded systems. Compliant with USB Type-C specifications, this connector delivers reliable connectivity in a minimal footprint.

Product Specifications

The UC31-1E1H1A103-0HR-30 USB Type-C 6-pin SMT connector conforms to the following specifications:

Key Features of the USB Type-C 6-Pin SMT Connector

• Compact 6-pin design – Simplified pinout with GND, VBUS, CC1, CC2 for cost-effective USB Type-C connectivity.
• Low 6.5mm profile – Ultra-low height suitable for slim devices and space-constrained PCB layouts.
• SMT mounting – Surface mount technology enables efficient automated pick-and-place assembly.
• USB 2.0 compatible – Supports data transfer and basic power delivery through CC1/CC2 configuration channels.
• 10,000 mating cycles – Durable contact design ensures long-term reliable connectivity.
• RoHS compliant – Environmentally friendly materials meeting international restriction standards.

Applications

• IoT devices and embedded systems requiring compact USB Type-C 6-pin SMT connector interfaces.
• Consumer electronics with USB 2.0 data transfer and charging via USB Type-C 6-pin SMT connector.
• Wearable devices and accessories needing low-profile USB Type-C 6-pin SMT connector solutions.
• Portable electronics requiring space-saving USB Type-C 6-pin SMT connector for data and power.
• Smart home devices and hubs using USB Type-C 6-pin SMT connector for basic connectivity.
• Embedded computing modules with USB Type-C 6-pin SMT connector for peripheral interfacing.

Why Choose VITALCONN USB Type-C 6-Pin SMT Connector

VITALCONN brings over a decade of connector manufacturing expertise to the USB Type-C 6-pin SMT connector product line. The UC31-1E1H1A103-0HR-30 undergoes rigorous quality testing including 10,000-cycle mating durability, contact resistance measurement, and insulation resistance verification. Manufactured in ISO-9000 certified facilities with UL certification, each USB Type-C 6-pin SMT connector meets international standards for safety and reliability. Explore our complete range of USB Type-C connectors for more options.

Frequently Asked Questions

Q: What USB standard does this USB Type-C 6-pin SMT connector support?
A: The UC31-1E1H1A103-0HR-30 supports USB 2.0 data transfer and basic Power Delivery through CC1/CC2 pins.

Q: What is the profile height of this USB Type-C 6-pin SMT connector?
A: The UC31-1E1H1A103-0HR-30 has a low profile height of 6.5mm, suitable for slim device designs.

Q: Can this USB Type-C 6-pin SMT connector support fast charging?
A: With 3A rated current on VBUS/GND pins and 20V rated voltage, it can support basic USB power delivery applications.

Q: What pin assignments are available on this USB Type-C 6-pin SMT connector?
A: The UC31-1E1H1A103-0HR-30 provides GND, VBUS, CC1, and CC2 pins for USB 2.0 data and configuration channel functionality.
